Gigabyte GA-Z87N-WIFI User Manual

- 11 -
Hardware Installation
USB  Chipset:
 - Upto4USB2.0/1.1ports(2portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
 - Upto6USB3.0/2.0ports(4portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
Internal
Connectors
 1x24-pinATXmainpowerconnector
 1x4-pinATX12Vpowerconnector
 4 x SATA 6Gb/s connectors
 1 x CPU fan header
 1 x system fan header
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.0/2.0 header
 1 x USB 2.0/1.1 header
 1 x serial port header
 1 x S/PDIF Out header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 2 x HDMI ports
 2 x antenna connectors
 1 x DVI-I port
 4 x USB 3.0/2.0 ports
 2 x USB 2.0/1.1 ports
 2 x RJ-45 ports
 1 x optical S/PDIF Out connector
 5x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out,LineIn,
LineOut,MicIn)
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 System voltage detection
 CPU/System temperature detection
 CPU/System fan speed detection
 CPU/System fan speed control
 * Whetherthefanspeedcontrolfunctionissupportedwilldependonthecooleryou
install.
BIOS  2x64Mbitash
 Use of licensed AMI EFI BIOS
 Support for DualBIOS
™
 PnP1.0a,DMI2.0,SMBIOS2.6,ACPI2.0a
