Gigabyte GA-Z87N-WIFI User Manual

Unique Features
- 78 -
5-2-1 EasyTune
GIGABYTE'sEasyTuneisasimpleandeasy-to-useinterfacethatallowsuserstone-tunetheirsystemsettings
or do overclock/overvoltage in Windows environment. The user-friendly EasyTune interface also includes tabbed
pagesforCPUandmemoryinformation,lettingusersreadtheirsystem-relatedinformationwithouttheneed
to install additional software.
The EasyTune Interface
Tabs Information
Tab Function
The System Information tab provides information on the installed CPU and motherboard.
Smart Quick Boost provides you with different levels of CPU frequency to choose to achieve
desiredsystemperformance.Aftermakingchanges,besuretorestartyoursystemforthese
changestotakeeffect.TheAdvancedmenuallowsyoutochangespecicclock/frequency/
votlage settings.
The Smart Fan tab allows you to specify a Smart Fan mode. The Calibrate menu displays
the detected linear fan speed for the fans on the motherboard from the fastest to the slowest.
TheAdvancedmenuallowsyoutosettemperaturethresholds,basedonwhichthefanspeed
can be changed linearly.
The System Alertstaballowsyoutomonitorhardwaretemperature,voltageandfanspeed
and set temperature/fan speed alarm.
The 3D Power tab allows you to change power phase and voltage settings.
Incorrectly doing overclock/overvoltage may result in damage to the hardware components such
asCPU,chipset,andmemoryandreducetheusefullifeofthesecomponents.Beforeyoudothe
overclock/overvoltage,makesurethatyoufullyknoweachfunctionofEasyTune,orsysteminstability
or other unexpected results may occur.
AvailablefunctionsinEasyTunemaydifferbymotherboardmodel.Grayed-outarea(s)indicatesthat
theitemisnotcongurableorthefunctionisnotsupported.
