- 7 -
KB_MS_USB
F_USB30
COM
DOUBLE_HDMI
CPU_FAN
LGA1150
ATX
GA-Z87N-WIFI
GA-H87N-WIFI
F_AUDIO
AUDIO
B_BIOS
M_BIOS
PCIEX16
DDR3_1
DDR3_2
BAT
ATX_12V
Intel
®
Z87 j
Intel
®
H87 k
DVI
ANTENNA_BRACKET
USB30_LAN1
USB30_LAN2
CODEC
SATA3_3
SATA3_2
SATA3_0
SATA3_1
CLR_CMOS
F_PANEL
iTE
®
Super I/O
(Note)
F_USB
WIFI Module
SYS_FAN
SPDIF_O
Atheros
®
GbE LAN
Intel
®
GbE LAN
GA-Z87N-WIFI/GA-H87N-WIFI Motherboard Layout
(Note) Thechipislocatedonthebackofthemotherboard.
j
Only for GA-Z87N-WIFI.
k
Only for GA-H87N-WIFI.
