Hardware Installation

- 28 -

11) F_USB (USB 2.0/1.1 Header)

 TheheadersconformtoUSB2.0/1.1specication.EachUSBheadercanprovidetwoUSBportsviaan

optionalUSBbracket.ForpurchasingtheoptionalUSBbracket,pleasecontactthelocaldealer.

Pin No. Denition

1 Power(5V)

2 Power(5V)

3 USBDX-

4 USB DY-

5 USBDX+

6 USB DY+

7 GND

8 GND

9 No Pin

10 NC

• DonotplugtheIEEE1394bracket(2x5-pin)cableintotheUSB2.0/1.1header.

• PriortoinstallingtheUSBbracket,besuretoturnoffyourcomputerandunplugthepowercord

from the power outlet to prevent damage to the USB bracket.

Pin No. Denition

1 NDCD-

2 NSIN

3 NSOUT

4 NDTR-

5 GND

6 NDSR-

7 NRTS-

8 NCTS-

9 NRI-

10 No Pin

12) COM (Serial Port Header)

The COM header can provide one serial port via an optional COM port cable. For purchasing the optional

COMportcable,pleasecontactthelocaldealer.

2 1

10 9

Gigabyte GA-Z87N-WIFI User Manual
