Appendix
- 98 -
Step 2:
Connect an audio device to an audio jack. The The current
connected device is dialog box appears. Select the device
according to the type of device you connect. Then click OK.
Step 3:
On the Speakersscreen,clicktheSpeaker Configuration
tab. In the Speaker Configurationlist,selectStereo,
Quadraphonic,5.1 Speaker,or7.1 Speaker according to
the type of speaker configuration you wish to set up. Then
the speaker setup is completed.
IfyourchassisprovidesanAC'97frontpanelaudiomodule,
toactivatetheAC'97functionality,clickthetoolicononthe
Speaker Configuration tab. On the Connector Settings
dialogbox,selecttheDisable front panel jack detection
check box. Click OK to complete.
Click Device advanced settings on the top right corner
on the Speaker Configuration tab to open the Device
advanced settings dialog box. Select the Mute the rear
output device, when a front headphone plugged in check
box. Click OK to complete.
B. Configuring Sound Effect
You may configure an audio environment on the Sound Effects tab.
C. Activating an AC'97 Front Panel Audio Module
D. Muting the Back Panel Audio (For HD Audio Only)D. Muting the Back Panel Audio (For HD Audio Only)
