Page 3-2 MDE-5422B Latitude™ Owner’s Manual · March 2021
Supplementary Instructions for
European Union (EU) Countries
Markings Related to Explosive Atmospheres (ATEX) Directive
Markings Related to Explosive Atmospheres (ATEX)
Directive
Specifications
Parameter Value
Operating Condition T3
Maximum Surface Temperature 200 °C (392 °F)
Three-phase Power Supply (For 3-phase motor only) 400 VAC +10 or - 20%
Single-phase Power Supply (For CDM and 1-phase motor) 230 VAC +10 or - 20%
Maximum Pressure 3.5 bar
Airborne Noise Emissions ≤ 67 dBA
The Latitude fuel dispenser is intended for use in an open location. The dispenser’s
electronics are suitable for use in condensing humidity. Ensure that you follow the
operating conditions and classes stated on the nameplate of the equipment.
IMPORTANT INFORMATION
