MDE-5422B Latitude™ Owner’s Manual · March 2021 Page 4-1

Dispenser Overview Latitude Components

4 – Latitude Components

Dispenser Overview

This chapter provides a description of the Latitude unit and its components.

Figure 4-1: Latitude Pump

(i) (ii)

Front View

Side View

Sl. No. Menu Sl. No. Menu

1 Motor 10 Pulser

2 Suction Unit 11 Inlet Filter

3 Junction Box (J-Box) 12 Spin on Filter

4 Side Flow Indicator 13 Meter

5 Hose 14 Nozzle

6 Reed Sensor 15 Nozzle Boot

7 Electronics Zone

8 Pump Breakaway

9 Valve
