MDE-5422B Latitude™ Owner’s Manual · March 2021 Page 5-11
Setting Parameters Latitude Operation
User Menu Mode
The following diagram shows the procedure for entering User Menu mode and viewing the
menu and sub-menu:
1 Press F1 followed by key 1 to enter in to the User Menu mode.
2 Enter the four-digit password and press ENTER. The DATE&TIME menu is displayed.
3 Press up or down arrow keys to scroll through the menus [see Figure 5-13 (v) and (vi)].
Figure 5-13: Entering User Menu Mode
(i) (ii)
(iii)
(iv) (v) (vi)
To open a sub-menu, proceed as follows:
a Press the ENTER key [see Figure 5-14 (i)on page 5-12].
b Select the TOTALIZER menu and press the ENTER key. The TOTALIZER sub-menu
CUM VOL is displayed [see Figure 5-14 (ii) on page 5-12].
c Press the down arrow key to view other available sub-menu.
