MDE-5422B Latitude™ Owner’s Manual · March 2021 Page 3-5

Zoning Diagram

Supplementary Instructions for

European Union (EU) Countries

Figure 3-3: Zoning Diagram for LS-300 Configuration

Hazardous Area For 4 Grade Models

Without Hose Retraction Feature

Hazardous Area For 4 Grade Models

With Hose Retraction Feature

Zone 0

Zone 1

Zone 2

External Zoning
