MDE-5422B Latitude™ Owner’s Manual · March 2021 Page 5-3
Working Principle Latitude Operation
3 Pull out the nozzle horizontally and dispense the fuel.
Figure 5-4: Pulling Out Nozzle
• After Fueling
To place back the nozzle in to the nozzle boot after dispensing the fuel, proceed as follows:
1 Push the nozzle horizontally into the nozzle boot after dispensing the fuel.
Figure 5-5: Pushing Nozzle Horizontally
(i)
Dispensing the Fuel
(ii)
Push Nozzle Horizontally
2 Lift the nozzle as shown in the following figure:
Figure 5-6: Lifting the Nozzle
