MDE-5422B Latitude™ Owner’s Manual · March 2021 Page 5-77
Setting Parameters Latitude Operation
Configuring Pump Manually Using CC
Setting Up Pump Configuration Type
To set up pump configuration type, proceed as follows:
1 Press F1 to open the CC menu and press 1 to enter the CC.
2 Enter the password and press ENTER.
3 Enter CC 90 and press ENTER.
4 Enter the desired value based on the pump configuration type and then press ENTER.
Note: The following are the val
ues for setting up the pump configuration type:
Pump Configuration Type Function Code
1P MPD 1
2P MPD 2
3P MPD 3
4P MPD 4
2P Quad 90
Duo Island 80
Retrieving Configuration and Logs from Dispenser in to USB
To retrieve configuration and logs from dispenser in to USB, proceed as follows:
1 Create the folder “ApolloConfig” in to the Pen Drive.
Note: Ensure that USB Drive is empty.
2 Copy the “WhoAreYou.pag” file in to the folder. This will be used to retrieve the configuration
and Log information.
Note: The *.pag file is provided by
the engineer to the service technician.
3 Plug the USB into the slot P4004.
Note: Ensure that the dispense
r is in idle state.
4 Press F2 > 8 on the keypad and observe as the Light Emitting Diodes (LEDs) glow in the
following sequence:
• D10 (Red): ON
• D11 (Green): OFF
5 Wait for the configuration and log information to download. The progress of download will be
visible on Keypad Display.
Note: Ensure that “Get config” is displayed
on both Keypad and Main Display.
