GIRBAU ED340 - Page 28

Location 28
Code No. 549758
Rev. nº 10/0418
Height of the work stations
ED260
ED340
ED460
ED660
H1
Air filter handles
mm
496
598
(in)
(19.5)
(23.5)
H2
Door opening height
mm
570
695
(in)
(22.4)
(27.4)
H3
Door handle
mm
888
1092
(in)
(35.0)
(43.0)
H4
Control panel
mm
1382
1689
(in)
(54.4)
(66.5)
H5
Breaker switch
mm
- - - - -
1677
(in)
- - - - -
(66.0)
H6
Steam air filter (vertical)
mm
1553
1859
(in)
(61.1)
(73.2)
H7
Steam air filter (horizontal)
mm
331/519
382/668
(in)
(13)/(20.4)
(15)/(26.3)
H8
Loading orifice
mm
611.996
737.497
(in)
(24.094)
(29.035)
H9
Feet
mm
3-35
3-35
(in)
(0.1)-(1.37)
(0.1)-(1.37)
H10
Pedestal
mm
264
145.5
(in)
(10.39)
(57.3)
