GIRBAU ED340 - REDUCED HEATING Power; Code No.

Connecting the machine 43
Code No. 549758
Rev. nº 10/0418
4.7.2. REDUCED HEATING power
MODELS WITH REDUCED ELECTRIC HEATING
VOLTAGE
(*1)
50/60 Hz
UNIT
ED260 ER
ED340 ER
ED460 ER
ED660 ER
Heating
power
200V
3Ph
kW
8.3
11.4
16.6
22.7
208V
3Ph
kW
9.0
12.3
18.0
24.6
220V
3Ph
kW
8.2
11.3
16.5
22.5
230V
3Ph
kW
9.0
12.3
18.0
24.6
240V
3Ph
kW
9.0
12.3
18.0
24.6
380V
3Ph
kW
8.2
11.2
16.4
22.4
400V
3Ph
kW
9.1
12.4
18.1
24.8
415V
3Ph
kW
9.0
12.3
17.9
24.5
VOLTAGE
(*2)
50/60 Hz
UNIT
ED260 ER
ED340 ER
ED460 ER
ED660 ER
Total
electrical
power
200V
3Ph
kW
9
12
18
24
208V
3Ph
kW
10
13
19
26
220V
3Ph
kW
9
12
18
24
230V
3Ph
kW
10
13
19
26
240V
3Ph
kW
10
13
19
26
380V
3Ph+N
kW
9
12
18
24
400V
3Ph+N
kW
10
13
19
26
415V
3Ph+N
kW
10
13
19
26
380V
3Ph
kW
9
12
18
24
400V
3Ph
kW
10
13
20
26
415V
3Ph
kW
9
12
25
26
Total
electrical
consumption
200V
3Ph
A
28
37
55
73
208V
3Ph
A
29
38
57
75
220V
3Ph
A
25
33
50
66
230V
3Ph
A
26
35
52
69
240V
3Ph
A
25
34
50
66
380V
3Ph+N
A
16
21
31
41
400V
3Ph+N
A
17
22
33
43
415V
3Ph+N
A
16
21
31
41
380V
3Ph
A
15
20
30
39
400V
3Ph
A
15
20
31
41
415V
3Ph
A
15
19
30
39
Note 1: voltage and connection phases of the heaters.
Note 2: voltage and connection phases of the dryer.
