Connecting the machine 45
Code No. 549758
Rev. nº 10/0418
4.9. Wiring diagram
CAUTION!
See areas of use in Section 3.2.
See heights for the work areas in Chapter 3 of this manual.
Models ED260, ED340,
ED460 and ED660
Models ED900 and ED1250
Gas and electric heating
Steam heating
Fig. 4.1
Fig. 4.2
Fig. 4.3
CAPTION
V1
Steam inlet
V2
Steam outlet
AFS1
AFS steam inlet
N
Distance from the axis of symmetry of the unit
H
Height from the machine base
E
Electrical conductor inlet
G
Gas inlet
EV
Fan extraction
