Connecting the machine 47
Code No. 549758
Rev. nº 10/0418
5. CONNECTING THE MACHINE
5.1. Electrical requirements
CAUTION!
THE ELECTRICAL WIRING EXTERNAL TO THE MACHINE, ITS CONNECTION TO THE MACHINE AND
SUBSEQUENT ADJUSTMENTS MUST BE CARRIED OUT BY A REGISTERED INSTALLATION
CONTRACTOR.
ALL THE MATERIALS USED IN THE ELECTRIC WIRING AS WELL AS ITS INSTALLATION MUST
COMPLY WITH THE LEGALLY APPROVED REGULATIONS CURRENTLY IN FORCE IN THE COUNTRY
OR AREA IN WHICH THE MACHINE IS BEING USED.
ALL THE INSPECTIONS AND TESTS CONCERNING ELECTRICAL WIRINGS MUST BE CARRIED OUT IN
ACCORDANCE WITH THE REGULATIONS CURRENTLY IN FORCE IN THE COUNTRY OR AREA IN
WHICH THE MACHINE IS BEING USED.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, THE EARTHING FOR THE MACHINE SHOULD
BE CHECKED BY A QUALIFIED TECHNICIAN. AN INADEQUATELY EARTHED INSTALLATION CAN
CREATE A RISK OF ELECTRIC SHOCK.
LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN
CAUSE IMPROPER OPERATION.
CAUTION!
CHECK THAT THE VOLTAGE AND FREQUENCY ON THE MACHINE’S SPECIFICATION NAMEPLATE
CORRESPOND TO THE MAINS VOLTAGE AND FREQUENCY.
THE VOLTAGE OF THE MACHINE’S CONTROL CIRCUIT IS 230 V AC.
CHECK THE DIRECTION OF ROTATION OF THE EXTRACTOR MOTOR.
CAUTION!
SPECIFIC WARNING FOR CE CERTIFIED MODELS, in accordance with Standard EN-61000-3-11:2002.
THE SUPPLY NETWORK IMPEDANCE MUST BE LOWER THAN:
ED460E / ED660E MODELS: (0.265+j0.172) Ohm.
CAUTION!
SPECIFIC CAUTION FOR USA/CANADA MACHINES
GROUNDING INSTRUCTIONS
THIS APPLIANCE MUST BE CONNECTED TO A GROUNDED METAL, PERMANENT WIRING SYSTEM,
OR AN EQUIPMENT-GROUNDING CONDUCTOR MUST BE RUN WITH THE CIRCUIT CONDUCTORS
AND CONNECTED TO THE EQUIPMENT-GROUNDING TERMINAL OR LEAD ON THE APPLIANCE.
THIS APPLIANCE MUST BE ELECTRICALLY GROUNDED IN ACCORDANCE WITH LOCAL CODES OR,
IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 OR
THE CANADIAN ELECTRICAL CODE, CSA C22.1.
