GIRBAU ED340 - Machines with Electric Heating

Connecting the machine 34
Code No. 549758
Rev. nº 10/0418
4.2.2. Machines with electric heating
Nameplate:
Heating ........................... E
Voltage ........................... 200…240
Phases ........................... 3Ph
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 200…240
Phases ........................... 3Ph
Number of wires
3Ph + PE/GND
ED260 ER
Wire section
mm
2
6
AWG
10
Automatic External Switch
A
32
ED260 EN
ED340 ER
Wire section
mm
2
10
AWG
8
Automatic External Switch
A
40
ED340 EN
ED460 ER
Wire section
mm
2
10
AWG
4
Automatic External Switch
A
63
ED460 EN
ED660 ER
Wire section
mm
2
25
AWG
2
Automatic External Switch
A
80
ED660 EN
Wire section
mm
2
35
AWG
1
Automatic External Switch
A
100
Nameplate:
Heating ........................... E
Voltage ........................... 230…240
Phases ........................... 3Ph
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 230…240
Phases ........................... 3Ph
Number of wires
3Ph + PE/GND
ED900
Wire section
mm
2
95
AWG
4/0
Automatic External Switch
A
139.1
