GIRBAU ED340 - Exhaust Ducting Specifications

Connecting the machine 44
Code No. 549758
Rev. nº 10/0418
4.8. Exhaust ducting. Technical and connection details
This information should be supplemented with images and information from Section 5.5.
UNIT
ED260
ED340
ED460
ED660
ED1250
Connection diameter of
the exhaust duct
mm
(in)
150
(5.9)
150
(5.9)
200
(7.9)
200
(7.9)
300
(11.8)
Connection height of the
exhaust duct
mm
(in)
115
(4.5)
115
(4.5)
140
(5.5)
140
(5.5)
228.3
(9)
Extraction flow (*1)
m3/h
(cu ft/h)
665
(23484)
697
(24614)
1363
(48116)
1402
(49511)
2500
(88287)
Maximum pressure of the
extraction duct (*2)
mmH
2
O
(in wc)
7
(0.28)
7
(0.28)
7
(0.28)
7
(0.28)
1.6
(0.06)
Note 1: Values registered with the machine empty and output free.
Note 2: Maximum pressure. Registered with the machine running empty and at a distance of approximately 1 m (40 in)
from the exhaust duct connection.
