CAUTION!
AFTER CHANGING THE TYPE OF GAS:
Fill in and affix the gas type change label
Check the machine operation as described in chapter 8 - initial start-up.
Assemble and fix all the machine’s covers back in place.
5.4.1. Gas type change label
THIS EQUIPMENT WAS CONVERTED ON (DAY-MONTH-YEAR)………(1)…..…
TO……(2)………. GAS WITH KIT No ….(3)……BY…………(4)…………………
(name and address of organization making this conversion, who accepts the
responsibility for the correctness of this conversion).
PRESSURE ....................................................... (5) .............................. mbar
CONSUMPTION (PROPANE GAS) ................. (6) ............................... kg/h
(NATURAL GAS) ................ (7) .............................. m
3
/h
NOMINAL HEAT CONSUMPTION (Hi) ........... (8) ............................... kW
ORIFICE (DIAMETER) ....................................... (9) .............................. mm
Gas type change label fields
(1) Date of the change
(2) Type of gas the dryer is to be changed to
(3) Part number of the gas change kit
(4) Organisation, company or ATS that has carried out the change.
(5) Gas supply pressure
(6) Massic consumption; models supplied with propane gas
(7) Volumetric consumption; models supplied with natural gas
(8) Nominal calorie consumpt. with regard to H
i
(9) Injector diameter.
Refer to the machine’s parts list for the part numbers of the various conversion kits.
See Section 4.3 for values of fields 5, 6, 7, 8 and 9.
