GIRBAU ED340 - Electric Heating Specifics

Connecting the machine 42
Code No. 549758
Rev. nº 10/0418
4.7. Specific values for models with electric heating
4.7.1. NOMINAL HEATING power
MODELS WITH NOMINAL ELECTRIC HEATING
VOLTAGE (*1)
50/60 Hz
UNIT
ED260 EN
ED340 EN
ED460 EN
ED660 EN
ED1250 EN
Heating
power
200V
3Ph
kW
11.4
16.6
22.7
28.4
-
208V
3Ph
kW
12.3
18.0
24.6
30.8
-
220V
3Ph
kW
11.3
16.5
22.5
28.1
-
230V
3Ph
kW
12.3
18.0
24.6
30.8
-
240V
3Ph
kW
12.3
18.0
24.6
30.8
-
380V
3Ph
kW
11.2
16.4
22.4
25.7
66.3
400V
3Ph
kW
12.4
18.1
24.8
31.0
73.5
415V
3Ph
kW
12.3
17.9
24.5
30.6
72.7
VOLTAGE (*2)
50/60 Hz
UNIT
ED260 EN
ED340 EN
ED460 EN
ED660 EN
ED1250 EN
Total
electrical
power
200V
3Ph
kW
12
17
24
30
-
208V
3Ph
kW
13
19
26
32
-
220V
3Ph
kW
12
17
24
30
-
230V
3Ph
kW
13
19
26
32
-
240V
3Ph
kW
13
19
26
32
-
380V
3Ph+N
kW
12
17
24
30
-
400V
3Ph+N
kW
13
19
26
32
-
415V
3Ph+N
kW
13
19
26
32
-
380V
3Ph
kW
12
17
22
27
68.5
400V
3Ph
kW
12
18
26
33
75.7
415V
3Ph
kW
13
18
25
32
74.9
Total
electrical
consumptio
n
200V
3Ph
A
37
52
72
85
-
208V
3Ph
A
38
54
75
92
-
220V
3Ph
A
33
47
66
81
-
230V
3Ph
A
34
49
68
84
-
240V
3Ph
A
33
47
66
81
-
380V
3Ph+N
A
20
29
40
46
-
400V
3Ph+N
A
21
30
42
52
-
415V
3Ph+N
A
21
29
41
50
-
380V
3Ph
A
19
27
39
44
104.3
400V
3Ph
A
20
29
40
50
109.4
415V
3Ph
A
19
27
39
48
104.3
Note 1: voltage and connection phases of the heaters.
Note 2: voltage and connection phases of the dryer.
