GIRBAU ED340 - Models with Gas or Steam Heating

Connecting the machine 32
Code No. 549758
Rev. nº 10/0418
4.2.1. Models with gas or steam heating
Nameplate:
Heating ........................... G/V
Voltage ........................... 200…240
Phases ........................... 1Ph + N
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 200…240
Phases ........................... 1Ph + N
Number of wires
2 + PE/GND
ED260
ED340
Wire section
mm
2
1.5
AWG
14
Automatic External Switch
A
6
ED460
ED660
Wire section
mm
2
1.5
AWG
14
Automatic External Switch
A
10
Nameplate:
Heating ........................... G/V
Voltage ........................... 200…240
Phases ........................... 1Ph + N
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 200…240
Phases ........................... 2Ph
Number of wires
2 + PE/GND
ED260
ED340
Wire section
mm
2
1.5
AWG
14
Automatic External Switch
A
6
ED460
ED660
Wire section
mm
2
1.5
AWG
14
Automatic External Switch
A
10
Nameplate:
Heating ........................... G/V
Voltage ........................... 200…240
Phases ........................... 1Ph + N
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 200…240
Phases ........................... 3Ph
Number of wires
2 + PE/GND
ED260
ED340
Wire section
mm
2
1.5
AWG
14
Automatic External Switch
A
6
ED460
ED660
Wire section
mm
2
1.5
AWG
14
Automatic External Switch
A
10
