GIRBAU ED340 - Page 35

Connecting the machine 35
Code No. 549758
Rev. nº 10/0418
Nameplate:
Heating ........................... E
Voltage ........................... 380…415
Phases ........................... 3Ph + N
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 380…415
Phases ........................... 3Ph + N
Number of wires
4 + PE/GND
ED260 ER
Wire section
mm
2
4
AWG
12
Automatic External Switch
A
20
ED260 EN
ED340 ER
Wire section
mm
2
4
AWG
10
Automatic External Switch
A
25
ED340 EN
ED460 ER
Wire section
mm
2
6
AWG
8
Automatic External Switch
A
40
ED460 EN
ED660 ER
Wire section
mm
2
10
AWG
6
Automatic External Switch
A
50
ED660 EN
Wire section
mm
2
16
AWG
4
Automatic External Switch
A
63
Nameplate:
Heating ........................... E
Voltage ........................... 380…415
Phases ........................... 3Ph
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 380…415
Phases ........................... 3 Ph
Number of wires
2 + PE/GND
ED900
ED1250
Wire section
mm
2
70
AWG
3/0
Automatic External Switch
A
108.7
