Connecting the machine 59
Code No. 549758
Rev. nº 10/0418
CAUTION!
THE GAS VALVE ADJUSTMENT MUST BE LEFT UNALTERED.
 Replace and secure ALL the covers.
 Start up the machine and select a program with temperature to cause the burner to ignite (see directions in
Chapter 8).
 Based on the result of the analysis of the combustion gases, if necessary, adjust the position of the
deflector until the correct amount of combustion is obtained.
Adjusting the position of the deflector
TYPE OF GAS
ED1250
mm
(in)
NATURAL
20
(0.79)
PROPANE 37 mbar / 14.85 in.wc
43
(1.69)
PROPANE 50 mbar / 20.07 in.wc
23
(0.90)
