Operations & Maintenance Manual: Setting Up
PROCEDURE 2. MOUNT THE SYSTEM (OPTIONAL)
If you choose to mount the system, you may use either of the following configurations:
• Mount it on a GlideScope premium cart or AVL portable stand (Figure 8 or Figure 9). These solutions
make it easy for you to move the system from one location to another.
• Mount it on an IV pole (Figure 10).
Figure 8. GlideScope Premium Cart Figure 9. AVL Portable Stand Figure 10. IV Pole Mount
IV pole mount
ATTACH THE MONITOR TO THE CART OR IV POLE
1. If you are using the GlideScope premium cart or AVL portable stand, assemble it according to the
instructions included with the component.
2. If you are using an IV pole mount, place the mounting bracket on the IV pole, and then tighten the bracket
attachment knob until the IV pole mount is secure.
Bracket attachment knob
