Goodwe GW10K-ET User Manual

13
03 Product IntroductionUser Manual V1.1-2022-12-20
Back-up mode
NOTICE
• The back-up mode is mainly applied to the scenario where the grid is unstable and there
is an important load. When the grid is disconnected, the inverter turns to o-grid mode to
supply power to the load; when the grid is restored, the inverter switches to on-grid mode.
• The battery stops discharging when it reaches SOC. When there is sunlight the next day,
the battery starts to supply power to the load after it is charged to a certain power level.
• When the power generated in the PV system is sucient, it charges the battery as priority.
And the excess power charges the load. The remaining power will be sold to the grid.
• When there is no power generated in the PV system:
• The grid will supply the load when it is normal.
• The inverter will enter o-grid mode and the battery will supply power to the load when
the grid is abnormal.

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
