Goodwe GW10K-ET User Manual

55
09 Maintenance
User Manual V1.1-2022-12-20
No. Fault Cause Solutions
9 Anti-islanding
The utility grid
is disconnected.
The utility grid
is disconnected
according to the
safety regulations,
but the grid voltage
is maintained due
to the loads.
1. Check whether the utility grid is
disconnected.
2. Contact the dealer or the after-sales
service.
10
LVRT
Undervoltage
Utility grid
exception. The
duration of
the utility grid
exception exceeds
the set time of
LVRT.
1. If the problem occurs occasionally, the
utility grid may be abnormal temporarily.
The inverter will recover automatically
after detecting that the utility grid is
normal.
2. If the problem occurs frequently, check
whether the grid frequency is within the
permissible range. If not, contact the local
power company. If yes, contact the dealer
or the after-sales service.
11
HVRT
Overvoltage
Utility grid
exception. The
duration of utility
grid exception
exceeds the set
time of HVRT.
12
Abnormal GFCI
30mA
The input insulation
impedance
becomes low when
the inverter is
working.
1. If the problem occurs occasionally, it
may be caused by a cable exception. The
inverter will recover automatically after
the problem is solved.
2. Check whether the impedance between
the PV string and PE is too low if the
problem occurs frequently or persists.
13
Abnormal GFCI
60mA
14
Abnormal GFCI
150mA
15 Abnormal GFCI
16
Large DC of AC
current L1
The DC component
of the output
current exceeds
the safety range or
default range.
1. If the problem is caused by an external
fault like a utility grid exception or
frequency exception, the inverter will
recover automatically after solving the
problem.
2. If the problem occurs frequently and the
PV station cannot work properly, contact
the dealer or the after-sales service.
17
Large DC of AC
current L2

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
