Accessories
USE ONL
Y
GENUINE
GRACO
P
ARTS AND ACCESSORIES
French 185–956
Spanish 185–961
German 186–041
Greek 186–045
Korean 186–049
English 185–593
0162
DANGER
LABELS
The English language DANGER label shown on
page
1 is also on your
sprayer
. If you have painters
who
do not read English, order one of the following
labels to apply to your sprayer.
The drawing below
shows the best placement of these labels for good
visibility.
Order the labels directly from Graco, free of
charge. Toll Free: 1–800–328–0211
Apply
other
language here
Displacement
Pump Repair Kit
220–877
Parts
included in the kit are shown on page 34. Repair in
-
structions
are on page 31 of this manual and are also in
-
cluded
with the kit.
Sleeve Removal T
ool 224–788
Required for removing the displacement pump sleeve.
55 Gallon (200 Liter) Suction Tube Kit
208–259
Includes:
Ref
No. Part No. Description Qty
1 156–589 UNION, 90
ADAPTER, 3/4 npt(f) x
3/4 npsm(f) swivel 1
2 214–961
HOSE, coupled 3/4 npt(mbe)
3/4” ID; nylon, 6 ft (1.8 m);
spring guard one end
1
3 156–591 ELBOW
, 90
; 3/4 npt x 1–1/2 – 24 NS
1
4 156–593 P
ACKING, o–ring, nitrile rubber
1
5 100–220 THUMBSCREW
, 5/16–18 x 1”
1
6 176–684
ADAPTER, bung
1
7 156–592 TUBE, riser 1
8 159–100 RETAINER, screen 1
9 161–377 SCREEN, filter 1
10 159–101 NUT
, screen retainer
1
0162
2
1
5
3
4
6
7
8
9
10
5 Gallon (19 Liter) Suction Tube Kit
208–920
Includes:
Ref
No. Part No. Description Qty
1 101–818 CLAMP
, hose
2
2 160–327 UNION, 90
swivel; 3/4 npt(m x f)
1
3 170–705 ADAPTER, intake 1
4 170–706 HOSE, 1” ID x 48”; nylon 1
5 170–957 TUBE, suction 1
6 181–072 STRAINER 1
6
5
1
4
1
3
2
0161
Heavy Duty 5 Gallon (19 Liter) Suction Tube Kit
223–934
Includes:
Ref
No. Part No. Description Qty
1 183–770 STRAINER 1
2 110–962 SUCTION TUBE 1
3 110–964 HOSE CLAMP 2
4 186–245 SPRING CLIP 2
5 170–706 SUCTION HOSE 1
6 110–960 UNION 1
7 805–077 DRAIN TUBE 1
8 108–982 TUBE CONNECTOR 1
9 103–473 PLASTIC TIE 1
10 176–450 HOSE GUARD 1
0164
10
9
9
5
7
8
3
3
4
1
6
2
