Graco Reactor 2 E-XP2 Operation

AdvancedDisplayModule(ADM)
Icons Icons
Icons
Icons Icons
Icons
Icon Icon
Icon
Function Function
Function
ComponentA
ComponentB
EstimatedSupplyMaterial
HoseTemperature
JogModeSpeed
Pressure
CycleCounter(pressand
hold)
Advisory.
SeeErrors,page40formore
information.
Deviation.
SeeErrors,page40formore
information
Alarm.
SeeErrors,page40formore
information
Softkeys Softkeys
Softkeys
Icon Icon
Icon
Function Function
Function
StartProportioner
StartandStopProportionerinJogMode
StopProportioner
Turnonoroffthespeci󰘰edheatzone.
Parkpump
EnterJogMode.SeeJogMode,page48
ResetCycleCounter
(pressandhold)
SelectRecipe
Search
MoveCursorLeftOneCharacter
MoveCursorRightOneCharacter
Togglebetweenupper-case,lower-case,and
numbersandspecialcharacters.
Backspace
Cancel
Clear
TroubleshootSelectedError
Increasevalue
Decreasevalue
Nextscreen
Previousscreen
Returnto󰘰rstscreen
22
333023M
