Graco Reactor 2 E-XP2 Operation

PressureReliefProcedure
Pressure Pressure
Pressure
Relief Relief
Relief
Procedure Procedure
Procedure
FollowthePressureReliefProcedure
wheneveryouseethissymbol.
Thisequipmentstayspressurizeduntilpressure
ismanuallyrelieved.Tohelppreventserious
injuryfrompressurized󰘱uid,suchasskininjection,
splashing󰘱uidandmovingparts,followthe
PressureReliefProcedurewhenyoustopspraying
andbeforecleaning,checking,orservicing
equipment.
TheFusionAPgunisshown.
1.Relievepressureingunandperformgun
shutdownprocedure.Seegunmanual.
2.Engagegunpistonsafetylock.
3.Closegun󰘱uidinletvalvesAandB.
4.Shutofffeedpumpsandagitator,ifused.
5.Route󰘱uidtowastecontainersorsupplytanks.
TurnPRESSURERELIEF/SPRAYvalves(SA,
SB)toPRESSURERELIEF/CIRCULATION
.Ensuregaugesdropto0.
SA
SB
GA
GB
333023M57
