Graco Reactor 2 E-XP2 Operation

Spraying
Spraying Spraying
Spraying
TheFusionAPgunisshown.
1.Engagegunpistonsafetylockandclosegun
󰘱uidinletvalvesAandB.
Fusion Fusion
Fusion
Probler Probler
Probler
2.Attachgun󰘱uidmanifold.Connectgunairline.
Openairlinevalve.
3.Adjustthegunairregulatortodesiredgunair
pressure.Donotexceedthemaximumrated
airpressure.
4.SetPRESSURERELIEF/SPRAYvalves(SA,
SB)toSPRAY .
SB
SA
GA
GB
5.Verifyheatzonesareonandtemperatures
andpressuresareontarget,see
Homescreen,page38.
6.Open󰘱uidinletvalvelocatedateachpumpinlet.
7.Press tostartmotorandpumps.
8.Check󰘱uidpressuregauges(GA,GB)to
ensureproperpressurebalance.Ifimbalanced,
reducepressureofhighercomponentby
slightly slightly
slightly
turningPRESSURERELIEF/SPRAY
valveforthatcomponenttowardPRESSURE
RELIEF/CIRCULATION
untilgaugesshow
balancedpressures.
SA
SB
GA
GB
