1.Removebolts(A)andnuts.
2.Swinguptheelectricalenclosureandreinstall
bolt(A)withnut.Tightenbolt(B)andnut.
3.Positioncablebundlesagainsttheframeand
attachtotheframewithloosewiretie(C)on
eachside.
Topreventseriousinjuryduetosystemtipping
over,ensureReactorisproperlysecuredtowall.
Note
Mountingbracketsandboltsareincludedinthebox
oflooseparts,shippedwithyoursystem.
1.Usethesuppliedboltstoinstallthesupplied
L-bracketsontothesystemframeinthetop-most
squareholes.Installbracketsonboththeleft
andrightsideofsystemframe.
2.SecuretheL-bracketstothewall.IfL-brackets
donotlineupwiththewallstudspacing,bolta
pieceofwoodtothestudsthensecureL-brackets
towood.
3.Usethefourholesinthebaseofthesystem
frametosecurebasetothe󰘱oor.Boltsnot
supplied.
26333023M
