Graco Reactor 2 E-XP2

PerformanceCharts
Heater Heater
Heater
Performance Performance
Performance
Chart Chart
Chart
140
(60.0)
130
(54.4)
120
(48.9)
110
(43.3)
100
(37.8)
90
(32.2)
80
(26.6)
70
(21.1)
60
(15.5)
50
(10.0)
40
(4.4)
30
(-1.1)
20
(-6.6)
10
(-12.2)
0 0.5
(1.9)
1.0
(3.8)
1.5
(5.7)
2.0
(7.6)
2.5
(9.5)
3.0
(11.4)
3.5
(13.2)
4.0
(15.1)
4.5
(17.0)
L
K
ti28705a
DeltaTin
degreesF
(degreesC)
FlowRateingpm(lpm)
* Heaterperformancedataisbasedontestingwith10wt.hydraulic
oiland230Vacrossheaterpowerwires.
KEY: KEY:
KEY:
K=10.2kW
L=15.3kW
70333023M
