Grandstream Networks GSC35 Series User Manual

GSC35XX Series User Manual
Version 1.0.0.15
P a g e | 17
GSC3510/GSC3505 Ports
Figure 2: GSC3510/GSC3505 Ports
Table 4: GSC3510/GSC3505 Ports Description
NO.
Name
Description
RESET
Factory reset button. Press for 10 seconds to reset factory default
settings.
NET/PoE
Ethernet RJ45 port (10/100Mbps) supporting PoE/PoE+.
2-PIN Port
2-PIN Multi-Purpose Input Port.
GSC3510/GSC3505 LED Indicators
The GSC3510/GSC3505 contains 4 types of colored LEDs (Red, Green, White and Blue light) that are used
in some specific situations and operations. Please, refer to the following table describing each one of the
LED Indicators status:
Table 5: GSC3510 LED Indicators
Color
LED Indicator Status
Description
Red Light
Fast Flashing (every 1s)
Rebooting/factory resetting
Slow Flashing (On 1s, Off 2s)
Unhandled event: (Included Missed call(s), new voice
mails, new SIP messages).
Solid Red
The contacts/storage space is full
Green Light
Fast Flashing (every 1s)
Incoming/outgoing call
Slow Flashing (On 1s, Off 2s)
Call on hold.
Solid Green
During the call.
White Light
Fast Flashing (every 1s)
Upgrading the firmware.
Blue Light
Fast Flashing (every 1s)
Bluetooth pairing.
2
3
1
1
2
3
