GSC35XX Series User Manual
Version 1.0.0.15
Virtual Account Group
Avaya Mode
If set to "Yes", when processing SIP Register 3XX Response, it will parse
the address site in 3XX, modify the account server info "SIP Server: port"
& "SIP Transaction" in virtual account group and initiate registration again.
This feature is designed for the Avaya customers.
Sets the characters for filter when dial out numbers. Users could set up
multiple characters. For example, if set to “[()-]”, when dial (0571)-8800-
8888, the character “()-“ will be automatically filtered and dial
057188008888 directly.
Escape # as %23 in SIP
URI
Determines which characters will be included in the SIP INVITE URI if end
users input #. If it is set to “Yes”, the device will replace the # by %23.
Otherwise, it will include # in the SIP INVITE message.
The default setting is “Yes”.
Configures phone recording mode. If set to "Record locally", then will use
the local tape recorder for call recording, and the audio file will be saved in
accordance with the tape recorder setup. If set to "Record on PortaOne",
then will send the specified SIP messages to the corresponding server; If
set to "Record on UCM", then will send the recording feature code to the
UCM server to request for recording, and the recording function will be
executed by the server.
Sets operating environment for the device.
• When set to "Small and medium size room & used on desk", the
sound pickup range is increased and ENC is reduced;
• When set to "Large room & used on empty area", the sound pickup
range is reduced and ENC is increased.
The default value is "Large room & used on empty area".
Ring Tone
Available for the GSC3510 only
Auto Config CPT by
Region
Configures whether to choose Call Progress Tone automatically by region.
If set to "Yes", the device will configure CPT (Call Progress Tone)
according to different regions automatically. If set to "No", you can manual
configure CPT parameters. The default setting is "No".
