GSC35XX Series User Manual
Version 1.0.0.15
P a g e | 19
Ceiling Mount
1. Put the ceiling mounting (metal bracket) in the ceiling’s center and mark the position of the three
screws holes.
2. Drill a round hole with a diameter of 18mm for Ethernet cable. The distance between its center and
the highlighted hole on the plastic bracket should be 35mm.
3. Fix the plastic and metal brackets on the ceiling with flat-head screws and locknuts. Then place
and Ethernet cable pass through the 18mm-round hole.
4. Align the position line on device’s back cover with the positioning slot.–––
5. Rotate the device clockwise until it is locked on the right position.
Figure 7: Ceiling Mount - Step 1 & 2
Figure 8: Ceiling Mount - Step 3
Figure 9: Ceiling Mount - Step 4
Figure 10: Ceiling Mount - Step 5
