Grandstream Networks GXV3240 User Manual

GXV3240 User Manual
INSTALLATION
Grandstream Co., Ltd
Software Version：1.0.0.11 Document Version：0.1
12
Figure 2 GXV3240 Main Case-Back View
Table 2 GXV3240 Back View Icons
No.
Name
Specification
1
USB Port
Connect to USB device.
Note: Supports no USB keyboard or mouse device temporary. i.e.,
users could insert USB drive as well as USB Wi-Fi.
2
Handset Port
Connect handset.
3
RJ9 Headset Port
Connect headsets.
4
LAN Port
10/100/1000Mbps Ethernet port connect to LAN. It supports PoE.
5
PC Port
10/100/1000Mbps Ethernet port connect to PC.
6
Power Jack
12V/5A Power Jack used to connect the power adapter.
7
Extension Port
Connect the extension board.
8
Side Joint
Connect USB drive, SD card, 3.5mm headset and Mini HDMI cable.
Refer to figure 3 for more details.
