UCM6200 Series User Manual
Table 74: FAX/T.38 Settings
Enable Error
Correction Mode
Configure to enable Error Correction Mode (ECM) for the Fax.
The default setting is "Yes".
Maximum Transfer
Rate
Configure the maximum transfer rate during the Fax rate negotiation.
The possible values are 2400, 4800, 7200, 9600, 12000 and 14400.
The default setting is 14400.
Minimum Transfer Rate
Configure the minimum transfer rate during the Fax rate negotiation. The
possible values are 2400, 4800, 7200, 9600, 12000 and 14000. The default
setting is 2400.
Max Concurrent
Sending Fax
Configure the concurrent fax that can be sent by UCM6200. Two mode “Only”
and “More” are supported.
• Only
Under this mode, the UCM6200 allows only single user to send fax at a time.
• More
Under this mode, the UCM6200 supports multiple concurrent fax sending by
the users.
By default, this option is set to “only”.
Fax Queue Length
Configure the maximum length of Fax Queue from 6 to 10.
The default setting is 6.
Fax Header Information
Adds fax header into the fax file.
Default Email Address
Configure the Email address to send the received Fax to if user's Email address
cannot be found.
Note:
The extension's Email address or the Fax's default Email address needs to be
configured in order to receive Fax from Email. If neither of them is configured,
Fax will not be received from Email.
Template Variables
Fill in the "Subject:" and "Message:" content, to be used in the Email when
sending the Fax to the users.
The template variables are:
• ${CALLERIDNUM} : Caller ID Number
• ${CALLERIDNAME} : Caller ID Name
• ${RECEIVEEXTEN} : The extension to receive the Fax
• ${FAXPAGES} : Number of pages in the Fax
• ${VM_DATE} : The date and time when the Fax is received
