Grandstream Networks UCM6208 User Manual

P a g e | 50
UCM6200 Series User Manual
Table 7: UCM6200 Network Settings802.1X
802.1X Mode
Select 802.1X mode. The default setting is "Disable". The supported 802.1X mode
are:
• EAP-MD5
• EAP-TLS
• EAP-PEAPv0/MSCHAPv2
Identity
Enter 802.1X mode Identity information.
MD5 Password
Enter 802.1X mode MD5 password information.
802.1X Certificate
Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
Static Routes
The UCM6200 provides users static routing capability that allows the device to use manually configured routes,
rather than information only from dynamic routing or gateway configured in the UCM6200 Web GUISystem
SettingsNetwork SettingsBasic Settings to forward traffic. It can be used to define a route when no other
routes are available or necessary, or used in complementary with existing routing on the UCM6200 as a failover
backup, etc.
• Click on to create a new static route. The parameters are listed in below table.
• Once added, users can select to edit the static route.
• Select to delete the static route.
Table 8: UCM6200 Network SettingsStatic Routes
Destination
Configure the destination IP address or the destination IP subnet for the UCM6200
to reach using the static route.
Example:
IP address - 192.168.66.4
IP subnet - 192.168.66.0
Netmask
Configure the subnet mask for the above destination address. If left blank, the
default value is 255.255.255.255.
Example:
255.255.255.0
