Grandstream Networks UCM6208 User Manual

P a g e | 97
UCM6200 Series User Manual
Version
Select the protocol version for the phone to send the bind requests. The default
value is 3.
Name Attribute
Specify the "name" attributes of each record which are returned in the LDAP
search result. Example:
• gn
• cn sn description
Number Attribute
Specify the "number" attributes of each record which are returned in the LDAP
search result. Example:
• telephoneNumber
• telephoneNumber Mobile
Display Name
Configure the entry information to be shown on phone's LCD. Up to 3 fields
can be displayed. Example:
• %cn %sn %telephoneNumber
Max Hits
Specify the maximum number of results to be returned by the LDAP server.
Valid range is 1 to 3000. The default value is 50.
Search Timeout
Specify the interval (in seconds) for the server to process the request and client
waits for server to return. Valid range is 0 to 180. The default value is 30.
Sort Results
Specify whether the searching result is sorted or not.
The default setting is No.
Incoming Calls
Configure to enable LDAP number searching when receiving calls. The default
setting is No.
Outgoing Calls
Configure to enable LDAP number searching when making calls. The default
setting is No.
Lookup Display Name
Configures the display name when LDAP looks up the name for incoming call
or outgoing call. It must be a subset of the LDAP Name Attributes.
XML Phonebook
Phonebook XML Server
Select the source of the phonebook XML server.
• Disable
Disable phonebook XML downloading.
• Manual
Once selected, users need specify downloading protocol HTTP, HTTPS or
TFTP and the server path to download the phonebook XML file. The server
path could be IP address or URL, with up to 256 characters.

Grandstream Networks UCM6208 Specifications

General

Brand	Grandstream Networks
Model	UCM6208
Category	PBX
Language	English
