Grandstream Networks UCM630 Series User Manual

P a g e | 156
UCM630X Series User Manual
Version 1.0.2.25
DND Time Condition
All time/Office time/out of office time/holiday/out of holiday/out
of office time or holiday/specific time
Do Not Disturb Whitelist
Empty/digits
User Password
Alphanumeric characters.
First Name
Alphanumeric without special characters.
Last Name
Alphanumeric without special characters.
Email Address
Email address
Language
Default/en/zh
Phone Number
Digits
Call-Barging Monitor
Extensions allowed to call barging
Seamless Transfer Members
Extensions allowed to seamless transfer
The CSV file should contain all the above fields, if one of them is missing or empty, the UCM630X will display
the following error message for missing fields.
Figure 82: Import Error
Extension Details
Users can click on an extension number in the Extensions list page and quickly view information about it such
as:
 Extension: Shows the Extension number.
 Status: Shows the status of the extension.
 Presence status: Indicates the Presence Status of this extension.
 Terminal Type: Shows the Type of the terminal using this extension (SIP, FXS…etc.).
 Caller ID Name: Reveals the Caller ID Name configured on the extension.
 Messages: Shows the messages stats.
 IP and Port: The IP address and the ports of the device using the extension.
 Email status: Show the Email status (sent, to be sent…etc.).
 Ring Group: Indicates the ring groups that this extension belongs to.
 Call Queue: Indicates the Cal Queues that this extension belongs to.
 Call Queue (Dynamic): Indicates the Call Queues that this extension belongs to as a dynamic agent.
