UCM630X Series User Manual
Version 1.0.2.25
Polarity on
Answer Delay
When FXO port answers the call, FXS may send a Polarity Reversal. If this interval is
shorter than the value of “Polarity on Answer Delay”, the Polarity Reversal will be
ignored. Otherwise, the FXO will Onhook to disconnect the call. The default setting is
600ms.
Current
Disconnect
Threshold (ms)
This is the periodic time (in ms) that the UCM630X will use to check on a voltage
drop in the line. The default setting is 200. The valid range is 50 to 3000.
Ring Timeout
Configure the ring timeout (in ms). Trunk (FXO) devices must have a timeout to
determine if there was a Hangup before the line is answered. This value can be used
to configure how long it takes before the UCM630X considers a non-ringing line with
Hangup activity. The default setting is 8000.
RX Gain
Configure the RX gain for the receiving channel of analog FXO port. The valid range
is from -13.5 (dB) to + 12.0 (dB). The default setting is 0.
TX Gain
Configure the TX gain for the transmitting channel of analog FXO port. The valid range
is from -13.5 (dB) to + 12.0 (dB). The default setting is 0.
Use CallerID
Configure to enable CallerID detection.
The default setting is “Yes”.
Caller ID Scheme
Select the Caller ID scheme for this trunk.
 Bellcore/Telcordia.
 ETSI-FSK During Ringing
 ETSI-FSK Prior to Ringing with DTAS
 ETSI-FSK Prior to Ringing with LR
 ETSI-FSK Prior to Ringing with RP
 ETSI-DTMF During Ringing
 ETSI-DTMF Prior to Ringing with DTAS
 ETSI-DTMF Prior to Ringing with LR
 ETSI-DTMF Prior to Ringing with RP
 SIN 227-BT
 NTT Japan
 Auto Detect
If you are not sure which scheme to choose, please select “Auto Detect”. The default
setting is “Bellcore/Telcordia”.
Fax Mode
Configures how faxes to this extension will be handled.
 None: Faxes will not be processed.
 Fax Gateway: Faxes to this extension will be processed and converted from
T.30 to T.38 or vice-versa. FXS/FXO ports only.
The default setting is None.
FXO Dial
Delay(ms)
Configure the time interval between off-hook and first dialed digit for outbound calls.
