UCM630X Series User Manual
Version 1.0.2.25
destination.
Advanced Settings
Codec Preference
Select audio and video codec for the VoIP trunk. The available codecs are: PCMU,
PCMA, GSM, AAL2-G.726-32, G.726, G.722, G.729, G.723, iLBC, ADPCM,
H.264, H.265, H.263, H.263p and VP8.
DID Mode
Configure where to get the destination ID of an incoming SIP call, from SIP
Request-line or To-header. The default is set to "Request-line".
DTMF Mode
Configure the default DTMF mode when sending DTMF on this trunk.
 Default: The global setting of DTMF mode will be used. The global setting
for DTMF Mode setting is under Web GUIPBX SettingsSIP
SettingsToS.
 RFC4733: Send DTMF using RFC4733.
 Info: Send DTMF using SIP INFO message.
 Inband: Send DTMF using inband audio. This requires 64-bit codec, i.e.,
PCMU and PCMA.
 Auto: Send DTMF using RFC4733 if offered. Otherwise, inband is used.
Enable Heartbeat
Detection
If enabled, the UCM630X will regularly send SIP OPTIONS to the device to check
if the device is still online. The default setting is "No".
Heartbeat Frequency
When "Enable Heartbeat Detection" option is set to "Yes", configure the interval
(in seconds) of the SIP OPTIONS message sent to the device to check if the device
is still online. The default setting is 60 seconds.
Maximum Number of
Call Lines
The maximum number of concurrent calls using the trunk. The default settings 0,
which means no limit.
Packet Loss
Retransmission
Configure to enable Packet Loss Retransmission.
Audio FEC
Configure to enable Forward Error Correction (FEC) for audio.
Video FEC
Configure to enable Forward Error Correction (FEC) for video.
FECC
Configure to enable Far-end Camera Control
SRTP
Enable SRTP for the VoIP trunk. The default setting is "No".
IPVT Mode
Configures the UCM to be used exclusively for IPVT. Warning: This will lock out
certain UCM features.
Sync LDAP Port
Configure the TCP port used LDAP sync feature between two peer UCM630X.
LDAP Outbound Rule
Specify an outbound rule for LDAP sync feature. The UCM630X will automatically
modify the remote contacts by adding prefix parsed from this rule.
LDAP Dialed Prefix
Specify the prefix for LDAP sync feature. The UCM630X will automatically modify
the remote contacts by adding this prefix.
