UCM630X Series User Manual
Version 1.0.2.25
Table 35: SIP Extension Configuration ParametersFeatures
Call Transfer
Presence Status
Select which presence status to set for the extension and configure call forward
conditions for each status. Six possible options are possible: “Available”, “Away”,
“Chat”, “Custom”, “DND” and “Unavailable”. More details at [PRESENCE].
Call Forward
Unconditional
Enable and configure the Call Forward Unconditional target number. Available options
for target number are:
 “None”: Call forward deactivated.
 “Extension”: Select an extension from dropdown list as CFU target.
 “Custom Number”: Enter a customer number as target. For example: *97.
 “Voicemail”: Select an extension from dropdown list. Incoming calls will be
forwarded to voicemail of selected extension.
 “Ring Group”: Select a ring group from dropdown list as CFU target.
 “Queues”: Select a queue from dropdown list as CFU target.
 “Voicemail Group”: Select a voicemail group from dropdown list as CFU target.
The default setting is “None”.
CFU Time
Condition
Select time condition for Call Forward Unconditional. CFU takes effect only during the
selected time condition. The available time conditions are “Office Time”, “Out of Office
Time”, “Holiday”, “Out of Holiday”, “Out of Office Time or Holiday” and “Specific”.
Note:
 “Specific” has higher priority to “Office Times” if there is a conflict in terms of time
period.
 Specific time can be configured under Specific Time section. Scroll down the add
Time Condition for specific time.
 Office Time and Holiday could be configured on page System SettingsTime
SettingsOffice Time/Holiday page.
Call Forward No
Answer
Configure the Call Forward No Answer target number. Available options for target
number are:
 “None”: Call forward deactivated.
 “Extension”: Select an extension from dropdown list as CFN target.
 “Custom Number”: Enter a customer number as target. For example: *97.
 “Voicemail”: Select an extension from dropdown list. Incoming calls will be
forwarded to voicemail of selected extension.
 “Ring Group”: Select a ring group from dropdown list as CFN target.
 “Queues”: Select a queue from dropdown list as CFN target.
 “Voicemail Group”: Select a voicemail group from dropdown list as CFN target.
The default setting is “None”.
CFN Time
Condition
Select time condition for Call Forward No Answer. The available time conditions are
“Office Time”, “Out of Office Time”, “Holiday”, “Out of Holiday”, “Out of Office Time or
Holiday” and “Specific”.
