P a g e | 98
UCM630X Series User Manual
Version 1.0.2.25
Security
Disable Telnet/SSH
Enable Telnet/SSH access for the SIP end device. If the SIP end device
supports Telnet access, this option controls the Telnet access of the device;
if the SIP end device supports SSH access, this option controls the SSH
access of the device.
Syslog
Syslog Server
Configure the URL/IP address for the syslog server.
Syslog Level
Select the level of logging for syslog.
Send SIP Log
Configure whether the SIP log will be included in the syslog message.
Table 28: Global Policy Parameters – Network Settings
Basic Settings
IP Address
Configure how the SIP end device shall obtain the IP address. DHCP or
PPPoE can be selected.
 DHCP
Once selected, users can specify the Host Name (option 12) of the SIP
end device as DHCP client, and Vendor Class ID (option 60) used by
the client and server to exchange vendor class ID information.
 PPPoE
Once selected, users need specify the Account ID, Password and
Service Name for PPPoE.
Host Name
Specifies the name of the client. This field is optional but may be required
by Internet Service Providers.
Vendor Class ID
Used by clients and servers to exchange vendor class ID.
Account ID
Enter the PPPoE account ID.
Password
Enter the PPPoE Password.
Service Name
Enter the PPPoE Service Name.
Advanced Setting
Layer 3 QoS
Define the Layer 3 QoS parameter. This value is used for IP Precedence,
Diff-Serv or MPLS. Valid range is 0-63.
Layer 2 QoS Tag
Assign the VLAN Tag of the Layer 2 QoS packets.
Valid range is 0 -4095.
Layer 2 QoS Priority Value
Assign the priority value of the Layer 2 QoS packets.
Valid range is 0-7.
STUN Server
Configure the IP address or Domain name of the STUN server. Only non-
symmetric NAT routers work with STUN.
Keep Alive
Select either to enable or disable Keep Alive.
