GRAPHTEC FC8600-60 - Pen Block Parts

FC8600-UM-251-9370 9-4
9 PARTS LIST
9.3 Pen Block
No. Part No. Description Q’ty Remarks Rank
1 792219702 Pen Holder Assy 4200 1 For 2-pen model A
2 621403032 Cutter Pen Holder 1 C
3 621353010 Thumb Screw L10 1 B
4 621403000 Pen Arm 1 These parts are part of pen
block assembly, replace
by the pen-block assembly
792800708.
D
5 621263230 Slide Shaft 1 D
6 682126520 Moving Coil with Yoke (PM1306) 1 D
7 617363351 Pen Encoder Strip 1 D
8 692140400 Pen Flexible Cable, FPC7071110 1 D
9 380205511 Pen Arm Spring E-551 1 D
10 792800709 Light Pointer Assy 1 A
11 621263251 Bearing Roller Base Bracket 1 Replace by the pen block assembly. D
12 310068320 Bearing Roller 2 683ZZMC3PS2S D
13 621403010 Moving Coil Base 1 Replace by the pen block assembly. D
14 500050122 Encoder Sensor, HEDS-9720#P50 1 Replace by the pen block assembly. D
15 - Registration Mark Sensor Assy 1 See Registration Mark Sensor Assy Part. -
16 792800711 Cross Cutter Assy 1 B
17 621113520 Rubber plate 1 Replace by the pen block assembly. D
18 622192091 Arm Spring 2 1 For 2-pen model
These parts are including
in the 2-pen option kit.
Therefore these parts are not
supplied as spare parts.
D
19 622192070 Lock Arm 2 D
20 053203420 Magnet 2 D
21 622192060 Pen Holder AP 2 D
22 337120250 Shaft Pin D2L25H7 2 D
23 333302001 Stopper Ring CS 2 mm 4 D
24 621409851 Pen Holder Spacer 1 D
25 622192081 Arm Spring 1 1 D
26 792219703 Pen Station Assy 4200 1 For 2-pen model B
27 792800708 Pen Block Assy 1 A
28 621263512 LED Base 1 C
