GRAPHTEC FC8600-60 - Page 81

FC8600-UM-251-9370 7-21
7 ADJUSTMENT
(7) Adjustthe40g-penforce.Ifthemeasuredvalueiswithinthespecicationrange(40±4g)orifyou
haveinputtherecordedvalue,presstheENTERkeytostorethesetting.Thenextspeciedpenforce
appears.
(8) Adjustthe120g-penforce.Ifthemeasuredvalueiswithinthespecicationrange(120±10g)orifyou
haveinputtherecordedvalue,presstheENTERkeytostorethesetting.Thenextspeciedpenforce
appears.
(9) Adjustthe300g-penforce.Ifthemeasuredvalueiswithinthespecicationrange(300±20g)orifyou
haveinputtherecordedvalue,presstheENTERkeytostorethesetting.Thenextspeciedpenforce
appears.
(10) Adjustthe400g-penforce.Ifthemeasuredvalueiswithinthespecicationrangeorifyouhaveinput
the recorded value, press the ENTER key to store the setting.
Note: When adjusting the pen force, it is important to do it quickly. Delaying the pen force adjustment
changesthetemperatureoftheactuatorandcausesarticiallylowerreadings.Whenthishappensthe
actualpenforcemaybehigherthanthespecication.Thisisespeciallytruefortheupperpenforce
adjustment.
(11) Press the NEXT key to complete this adjustment.
(12) Turn off the power to exit from the adjustment menu.
Specication of the actual pen force
Speciedpenforce
Actual force range
FC8600
10g 8 to 12g
40g 36 to 44g
120g 110 to 130g
300g 280 to 320g
400g 380 to 420g
