TransmiƩer Backside
1 BaƩery case cover
2 Gimbal tension screw for horizontal control funcƟon
3 no funcƟon
4
Gimbal tension screw for verƟcal control. Lower
screw is for tension of the control sƟck
5 ProporƟonal rotary control LV2
6
Inner screw adjusts brake force
Outer screw adjusts ratchet's strength
7 TransmiƩer handle
8 Foldable transmiƩer antenna
9 Cover ŇĂƉ for audio, COMM, DATA and DSC connecƟon
10
Inner screw adjusts brake force
Outer screw adjusts ratchet's strength
11 ProporƟonal rotary control LV1
12 Gimbal tension screw for horizontal control funcƟon
13
Gimbal tension screw for verƟcal control. Lower
screw is for tension of the control sƟck
14 no funcƟon
15 Cover of the USB connecƟon
