GRAUPNER mz-16 HoTT User Manual

Page 7 of 48 S1047.mz-16-V1.0-EN
Technical Data
T
ransmitter mz-16 HoTT
Frequency band 2404.056 ~ 2474.025 GHz
ModulaƟon FHSS
TransmiƫŶg power 100 mW EIRP
Channels 70 ~ 74
Control funcƟons 16 funcƟons of which 8 can be trimmed
16 digital switch funcƟons
Temperature range -10 - 55 °C / 14 – 130 °F
Antenna 1 linear with adjustable angle
OperaƟŶg voltage 3.6 … 4.35V
Power consumpƟon 480 to 1100mA
Dimensions Approx. 210 x 195 x 105mm
8.27 x 7.68 x 4.13in
Weight approx. 1120g/39oz with baƩery
Note
The technical informaƟon of Graupner receivers can be found in the related
receiver system manual or online.
W
iFi
Frequency Range 2412 MHz ~ 2474 MHz
Frequency Band IEEE 802.11 b/g/n HT20
Channels 11
ModulaƟon Type IEEE 802.11b: DSSS (CCK, DQPSK, DBSK);
IEEE 802.11g: OFDM (64QAM, 16QAM,
QPSK, BPSK); IEEE 802.11n HT20:
OFDM(64QAM, 16QAM, QPSK, BPSK)
Antenna Omni with 3.0 dBi gain
Bluetooth® 3.0+EDR (Optional Accessory)
Frequency Range 2402 MHz ~ 248- MHz
ModulaƟon Type GFSK, Pi/4 DQPSK, 8DPSK
Channels 79
Antenna PCB with 0 dBi gain
