Control SƟck
Length Adjustment
Neutralizing the SƟcks
Brake and Ratchet
SƟck Centering Force
Both sƟcks can be adjusted in length: By holding the lower half and turning
the upper part of the knurled handle, the screw is loosened. The control
sƟck is extended or shortened by turning it up or down
and then Įxed by screwing each against each other of the upper and lower
part of the handle.
Both control sƟcks can be set from neutralizing to non-neutralizing and vice
versa. Consult the transmiƩer backside diagram to locate the corresponding
set screws.
The respecƟǀe screw must be turned clockwise unƟů the control sƟck is free
to move from stop to stop or counterclockwise unƟů the control sƟck is again
self-neutralizing.
N
ote
Which of the two control sƟcks is to be switched to non-neutralizing also
depends on the choice of the control mode, see under "Commissioning the
transmiƩer".
On both control sƟcks, the braking force and strength of the ratchet can be
adjusted independently. Consult the transmiƩer backside diagram to locate
the corresponding set screws.
The inner set screw sets the braking force and the outer set screw sets the
strength of the ratchet of the verƟcal control direcƟon of the respecƟǀe
control sƟck.
The control sƟcks restoring force can also be adjusted. Consult the
transmiƩer backside diagram to locate the corresponding set screws. By
turning the respecƟǀe set screw, the spring force can be adjusted:
Right turn = return harder LeŌ turn = return soŌer
