Page 25 of 48 S1047.mz-16-V1.0-EN
1 RF status of the transmiƩer
2 RF status of the receiver
3 Screen lock on/oī
4 USB connecƟon connected/not connected
5 Headphones connected/not connected
6 DSC cable connected/not connected
7 Bluetooth on/oī
8 GPS signal available/not available
9 WLAN connected/not connected
10 Data logging on/oī
11 Widget and data clear icon
12 Help icon
13 BaƩery status, tapping switches between % and Volt
N
ote
All other indicaƟons on the display are freely interchangeable and are stored
model-speciĮĐ.
Main Display Symbols
