I. Recommendations for installation
The physical installation and connections must be done by a Gravotech approved
technician.
Turno󰓐themachinebeforeanyintervention.
1. Physical installation
• Placethemachineonahorizontal,stableandcleansurfacethatcansupport100kg(220.462lb)ormore.
• Checkthattheengravingtableislevelinbothdirections(adjustwithaspiritlevel.)
• Placethemachineinaclean,ventilatedenvironment.Choosethelocationthato󰘯erstheshortestand
most direct route to the air extraction system (see: "Air extraction system (optional)").
• Avoid small, con󰘰ned, unventilatedspaces. Somematerials continueto emitgases for afew minutes
afterlaser marking or cutting. The presence ofthese materials in acon󰘰ned, unventilated room could
contaminate the room.
To provide good ventilation and prevent the laser source, power supply and/or control unit
module from overheating, leave a clear space of 20 cm (7.874 in) all around the machine.
The back of the machine should be kept clear and should not be close to any items of
furniture. It must not be placed on a shelf or installed in a corner.
Overheatingcouldseriouslydamagethemachineandleadtomajorcosts.
This marking equipment is designed to function at a room temperature between 10 °C (50 °F) and 35
°C (95 °F).
• Iftheequipmentisstoredatatemperatureinferiorto10°C(50°F)orsuperiorto40°C(104°F),leave
it24hatatemperaturebetween10°C(50°F)and35°C(95°F)beforestart-up.Thedewpointambient
temperaturesmustbebelow10°C(50°F).
• Ambientlightisenoughtolighttheequipmentproperly.Themachinehasalightingsysteminsidethework
area.
• Arrangethe work areaso that theoperator can quickly and easily access all the external parts of the
machine. Do not obstruct the movement of the moving parts of the machine.
Make sure the connector screws are properly tightened to prevent the cables from
becoming disconnected while the machine is switched on. This could cause permanent
damage to the circuit boards.
Thepowercablemustalwaysbeeasilyaccessible(powershut-o󰓐device).
